Feature:
1. Life: Expected life span is about 20000 hours.
2. Low noise: ≤45dB, far from 1meter distance.
3. Duty work: The pump can sustain heavy duty work for a day. Continuous operation.
4. Working conditions: Applying to indoor and outdoor under temperature 40degC.
5.Working temperature: Within 75 degC.
6. It is waterproof and submersible.
7.It specially use for solar water circulation system, medical apparatus, fountain, aquarium,ect.
Reliable performance:works quietly;energy saving;high efficiency;environment protection; safe, no spark,
no virbration, no waste, very low noise, long life, ect. We can offer over voltage protection, overheat pro-
tection, run dry protection, over current protection, signal feedback, speed control, ect.
All the functions are custormized according to your request.
8. THE TECHNICAL SPECIFICATIONS BELOW IS ONLY FOR YOUR REFERENCE. IT CAN BE
CUSTORMIZED ACCORDING TO YOUR TECHINCAL REQUIREMENTS.
Caution: Do not operate for long time when there is no water in the pump.

Power supply:
It can be powered directly by Solar panel; DC electric source; battery.

Specification:
Model	Working voltage	Working current	Static lift	Static flowrate	Temp	Remarks
38#-08b	6VDC	1500mA	2.5 meter	7 L/min	≤100degC
	12VDC	1200mA	3.5 meter	9 L/min	≤100degC
	24VDC	700mA	4 meter	10 L/min	≤100degC
The tolerance of technical parameters above is ±10%
Remarks:The technical parameters above is only for your reference, for more detailes, please feel free to contact us
Structure dimensions
Model	Dimension(mm)	Inlet OD(mm)	Outlet OD(mm)	Remarks
38#-08b	87*47*98	M22	M22	Outlet and inlet have screw

Application:
       1. (Solar) water circulating system
       2. Solar water heater
       3. Aquarium
       4. Fountain
       5. Pressure boost,ect
