Feature:
1. The pump is Specially designed of THREE PHASE to enhence its power that is over 40watts.
2. Life: Expected life span is about 20000 hours.
3. Low noise: ≤ 45dB, far from 1meter distance.
4. Duty work: The pump can sustain heavy duty work for a day. Continuous operation.
5.Working conditions: Applying to indoor and outdoor under temperature 40degC.
6.Working temperature: Within 110 degC.
7. It is waterproof and can be submersible.
8.This pump is our newest design, it is made of ALUMINUM alloy material, has very good heat dissipation,
it can work in hot water a whole day,and its body temeprature is as the room temperature after long
working time. PC board can be outside of the pump or inside the pump, please tell us which type you prefer.
9. No vibration, safe and environment protection, no spark, low power cunsumption-high efficiency, ect.
10.It widely use for solar water circulation system, fountain, aquarium, garden, plant watering, household
dringk water,irrigation for small filed, automatic electric appliance, pipe pressurization, ect.
Reliable performance:works quietly;energy saving;high efficiency;environment protection;ect.
We can offer over voltage protection, overheat protection, run-dry protection, over current protection,
signal indication, speed control, ect. All the functions are custormized according to your requirement.
11. THE TECHNICAL SPECIFICATIONS BELOW IS ONLY FOR YOUR REFERENCE. IT CAN BE
CUSTORMIZED ACCORDING TO YOUR TECHINCAL REQUIREMENTS.
Caution: Do not operate for long time when there is no water in the pump.
Power supply:
It can be powered directly by Solar panel; DC electric source; battery.

Specification:
Model	Working voltage	Working current	Static lift	Static flowrate	Temp	Remarks
50#-06b	12VDC	2500mA	7 meter	14 L/min	≤110degC
	24VDC	2000mA	8 meter	15 L/min	≤110degC
The tolerance of technical parameters above is ±10%
Remarks:The technical parameters above is only for your reference, for more detailes, please feel free to contact us, you can provide us your detailed technical parameters.
Structure dimensions
Model	Dimension(mm)	Inlet OD(mm)	Outlet OD(mm)	Remarks
50#-06b	106*58*75	M16	11

Application:
      1.   Hot water circulating .
      2.   Aquarium
      3.   Fountain
      4. Medical treatment tools.
      5.   Irrigation
      6.   Pipe pressurizing
      7. Garden
